| 型号 | 额定电压 | 使用电压范围 | 额定电流 | 输入功率 | 额定转速 | 最大风量 | 最大静压 | 噪音 | ||
| [V] | [V] | [A] | [W] | [RPM] | [m3/h] | [CFM] | [mmAq] | [Pa] | [dB(A)] | |
| NDS6038H12XA | 12 | 5~13.8 | 0.35 | 4.2 | 8000 | 51.96 | 30.5 | 19.0 | 186.2 | 44.0 |
| NDS6038K12XA | 12 |
5~13.8 |
0.50 | 6.0 | 10000 | 66.06 | 38.8 | 30.1 | 295.0 | 50.3 |
|
NDS6038L12XA |
12 |
5~13.8 |
0.95 |
11.4 |
13000 | 83.82 | 49.3 | 46.8 | 458.8 | 54.5 |
|
NDS6038N12XA |
12 |
5~13.8 |
1.50 |
18.0 |
16000 | 103.68 | 61.0 | 66.2 | 649.0 | 58.8 |
|
NDS6038P12XA |
12 |
5~13.8 |
1.80 |
21.6 |
18000 | 116.58 | 68.6 | 77.5 | 759.8 | 62.0 |
|
NDS6038K24XA |
24 | 12~27.6 | 0.25 |
6.0 |
10000 | 66.06 | 38.8 | 30.1 | 295.0 | 50.3 |
|
NDS6038L24XA |
24 |
12~27.6 |
0.50 |
12.0 |
13000 | 83.82 | 49.3 | 46.8 | 458.8 | 54.5 |
|
NDS6038N24XA |
24 |
12~27.6 |
0.75 |
18.0 |
16000 | 103.68 | 61.0 | 66.2 | 649.0 | 58.8 |
|
NDS6038P24XA |
24 |
12~27.6 |
1.00 |
24.0 |
18000 | 116.58 | 68.6 | 77.5 | 759.8 | 62.0 |
|
NDS6038K48XA |
48 | 36~57.6 | 0.16 |
7.7 |
10000 | 66.06 | 38.8 | 30.1 | 295.0 | 50.3 |
|
NDS6038L48XA |
48 |
36~57.6 |
0.27 |
12.9 |
13000 | 83.82 | 49.3 | 46.8 | 458.8 | 54.5 |
|
NDS6038N48XA |
48 |
36~57.6 |
0.40 |
19.2 |
16000 | 103.68 | 61.0 | 66.2 | 649.0 | 58.8 |
|
NDS6038P48XA |
48 |
36~57.6 |
0.50 | 24.0 | 18000 | 116.58 | 68.6 | 77.5 | 759.8 | 62.0 |
|
RP |
SS | AS | CL | OV | CS |
| 反接保护 | 软启动 | 锁定保护 | 限流保护 | 过压保护 | 恒速保护 |
| 默认 | 默认 | 默认 | 可选 | 可选 | 可选 |
| FG | RD | LD |
| 转速侦测 | 停转告警 | 设定告警 |
| 可选 | 可选 | 可选 |
| PPWM | VPWM | TC | RC |
| 占控比调速 | 电压调速 |
温控调速 |
电阻调速 |
| 可选 | 可选 | 可选 | 可选 |
