| 型号 | 额定电压 | 使用电压范围 | 额定电流 | 输入功率 | 额定转速 | 最大风量 | 最大静压 | 噪音 | ||
| [V] | [V] | [A] | [W] | [RPM] | [m3/h] | [CFM] | [mmAq] | [Pa] | [dB(A)] | |
| NDS17251C12XC | 12 | 6~13.8 | 1.32 | 15.8 | 3350 | 426.6 | 251.0 | 18.0 | 176.4 | 55.0 |
| NDS17251D12XC | 12 |
6~13.8 |
4.40 | 52.8 | 4500 | 594.6 | 350.0 | 31.1 | 305.0 | 65.0 |
| NDS17251E12XA |
12 |
6~13.8 |
6.00 | 72.0 | 5200 | 666.0 | 393.3 | 44.2 | 433.3 | 69.0 |
| NDS17251C24XC |
24 |
12~27.6 | 0.66 | 15.8 | 3350 | 426.6 | 251.0 | 18.0 | 176.4 | 55.0 |
| NDS17251D24XC | 24 |
12~27.6 |
2.20 | 52.8 | 4500 | 594.6 | 350.0 | 31.1 | 305.0 | 65.0 |
| NDS17251E24XA | 24 |
12~27.6 |
3.00 | 72.0 | 5200 | 666.0 | 393.3 | 44.2 | 433.3 | 69.0 |
| NDS17251E24SC | 24 |
12~27.6 |
3.80 | 91.2 | 5400 | 660.0 | 388.5 | 64.0 | 627.2 | 76.0 |
| NDS17251F24SC | 24 |
12~27.6 |
3.30 | 79.2 | 6300 | 736.2 | 433.5 | 52.3 | 512.7 | 86.0 |
|
RP |
SS | AS | CL | OV | CS |
| 反接保护 | 软启动 | 锁定保护 | 限流保护 | 过压保护 | 恒速保护 |
| 默认 | 默认 | 默认 | 可选 | 可选 | 可选 |
| FG | RD | LD |
| 转速侦测 | 停转告警 | 设定告警 |
| 可选 | 可选 | 可选 |
| PPWM | VPWM | TC | RC |
| 占控比调速 | 电压调速 |
温控调速 |
电阻调速 |
| 可选 | 可选 | 可选 | 可选 |
